Overview

A Julia package for fast 3D image quilting simulation.

Build Status ImageQuilting Coverage Status

3D Quilting Animation

Features

  • Masked grids
  • Hard data conditioning
  • Soft data conditioning
  • Fast computation with GPUs

Installation

Get the latest stable release with Julia's package manager:

Pkg.add("ImageQuilting")

For even faster computation with GPUs, please follow the instructions in GPU support.

Usage

reals = iqsim(training_image::AbstractArray,
              tplsizex::Integer, tplsizey::Integer, tplsizez::Integer,
              gridsizex::Integer, gridsizey::Integer, gridsizez::Integer;
              overlapx=1/6, overlapy=1/6, overlapz=1/6,
              soft=nothing, hard=nothing, tol=.1,
              cut=:boykov, path=:rasterup, simplex=false, nreal=1,
              threads=CPU_PHYSICAL_CORES, gpu=false, debug=false, showprogress=false)

where:

required

  • training_image can be any 3D array (add ghost dimension for 2D)
  • tplsizex,tplsizey,tplsizez is the template size
  • gridsizex,gridsizey,gridsizez is the simulation size

optional

  • overlapx,overlapy,overlapz is the percentage of overlap
  • soft is an instance of SoftData or an array of such instances
  • hard is an instance of HardData
  • tol is the initial relaxation tolerance in (0,1]
  • cut is the cut algorithm (:dijkstra or :boykov)
  • path is the simulation path (:rasterup, :rasterdown, :dilation or :random)
  • simplex informs whether to apply or not the simplex transform to the image
  • nreal is the number of realizations
  • threads is the number of threads for the FFT (default to all CPU cores)
  • gpu informs whether to use the GPU or the CPU
  • debug informs whether to export or not the boundary cuts and voxel reuse
  • showprogress informs whether to show or not estimated time duration

The main output reals consists of a list of 3D realizations that can be indexed with reals[1], reals[2], ..., reals[nreal]. If debug=true, additional output is generated:

reals, cuts, voxs = iqsim(..., debug=true)

cuts[i] is the boundary cut for reals[i] and voxs[i] is the associated voxel reuse.

A helper function is also provided for the fast approximation of the mean voxel reuse:

mean, dev = voxelreuse(training_image::AbstractArray,
                       tplsizex::Integer, tplsizey::Integer, tplsizez::Integer;
                       overlapx=1/6, overlapy=1/6, overlapz=1/6,
                       cut=:boykov, simplex=false, nreal=10,
                       threads=CPU_PHYSICAL_CORES, gpu=false)

with mean in the interval $[0,1]$ and dev the standard deviation. The approximation gets better as nreal is made larger.
